C300 Controller Block
Server Displays tab
102 Experion C300 Controller User's Guide R301.1
Honeywell 11/06
Server Displays tab
The Server Displays tab is common to all configuration forms for tagged blocks in
Control Builder. The following table summarizes the parameter data you can monitor and
configure on this tab of the configuration form for the selected C300 block.
ATTENTION
The configuration settings you make for Server Load Options on the System
Preferences dialog determines whether or not the data entered on the
Server Displays tab is loaded to the Experion Server. See the Control
Building Guide for information about setting system preferences.
Plain Text Parameter Name
User
Configurable
Notes
Point Detail Display
SCANPNTDTL
Yes
By default, a Display
template is already entered
into Point Detail Display
box (for example,
sysDtlFTEB.dsp). This
template can be used for
creating your own display
or it can be used as is,
provided that your function
block name matches name
built into detail display that
is supplied as a template.
Group Detail Display
SCANGRPDTL
Yes
By default, a Display
template is already entered
into the Group Detail
Display box (for example,
sysGrpFTEB.dsp). This
template can be used for
creating your own display
or it can be used as is,
provided that your function
block name matches name
built into detail display that
is supplied as a template
Associated Display
SCANASSOCDSP
Yes
Name of the Server display
to be associated with this
function block.
