Viewing controller operation and status in Control Builder
FTE Status display
182 Experion C300 Controller User's Guide R301.1
Honeywell 11/06
A number of tabs on the configuration forms include parameters to indicate status and
numerous operating statistics. For example,Figure 9 shows the Statistics tab for a C300
Controller which includes CPU utilization and network messaging. Other tabs include
statistics on FTE communications and Peer connections. See C300 Configuration Form
Reference for more details on the parameters available on the configuration form tabs.
Figure 9 C300 Controller configuration form
