Initial load order guidelines
Load options for server history and server displays configuration
144 Experion C300 Controller User's Guide R301.1
Honeywell 11/06
Initial load order guidelines
Make the initial load of control strategy components from the Project tab in the following
order to minimize possible load interaction generated error messages. Use the Load
rather than the Load with Contents command.
Table 4 Initial Load Order Guidelines
Order Component
Post Load
Default State
1
A - C300 Platform
B - C300 IOLINK1
C - C300 IOLINK2
D - C300CEE
D – FTEB (if C300 contains the IOMs) See Notes 1 and 2
OK
OK
OK
IDLE
2
FTEB
3
Process Manager IOMs* IDLE
4
IOM* (Chassis I/O modules) INACTIVE
5
CM or SCM* INACTIVE
* Please refer to the Control Building Guide for more information about loading these
components.
Notes:
Loading the C300 platform block from project without contents will load the associated CEE
and IOLink blocks. All blocks must be configured before loading.
Appropriate errors will be returned in case of load failures.
For example, C300 not physically present at the configured address, C300 IOLINK Block
state FAILED, C300 CEE Block state FAILED, IOM physically not present, configuration
mismatches, etc…).
1. There are no restrictions as to when the I/O FTEB may be loaded, but to avoid I/O
errors it is recommended to load I/O FTEB before the C300 block.
2. The C300 FTEB I/O Manager will attempt to connect to the FTEB I/O chassis and load
the configuration data to the IOM. If the FTEB and/or IOM are not present, the C300 FTEB
I/O Manager will continue to attempt to establish communications and complete the
configuration.
