Honeywell Experion C300 User Manual

C300 Controller Block
Main tab
78 Experion C300 Controller User's Guide R301.1
Honeywell 11/06
Plain Text Parameter Name
User
Configurable
Notes
Item Name
Item Name
Project Only
A non-unique name by
which an entity is known
within the context of the
enterprise model.
Application Image
Version
IMAGEVER
No
Identifies current version
of application firmware
installed in module.
Controller Command
C300COMMAND
Monitoring
Only
Allows user to initiate
commands to a C300
Controller.
Network Address Configuration
Device Index
DEVICEIDX
Project Only
– Matches
Hardware
Setting
Unique FTE Device Index
of the C300 Controller.
Set on the C300 IOTA
switches.
Ethernet IP Address
IPADDRESS
No
IP address of the C300
Controller, derived as the
Embedded FTE Base
Ethernet IP Address plus
configured Device Index.
State Information
Controller State
C300STATE
No
Shows C300 Controller’s
current module state.
Redundancy Role
RDNROLESTATE
No
Shows C300 Controller’s
current redundancy role.
Synchronization
State
RDNSYNCSTATE
No
Shows C300 Controller’s
current synchronization
state.
Battery State
BATTERYNOTOK
No
Shows if battery voltage is
within ‘good’ range.
Soft Failures Present
(See Soft Failures
Tab for details)
SOFTFAIL
No
Indicates if Soft Failures
are currently active.
Redundancy Configuration
