Honeywell Performance Series User Manual

Performance Series Network Video Recorder User Guide
202
Note: You need to set the alarm recording period. Go to Storage 
Schedule

Record to configure the current channel for scheduled
recording.
Delay
The system can delay recording for a specified amount of time after an
alarm has ended. Select from 10s to 300s.
Alarm Out
Select the device output port, 1 or 2. Select the corresponding port(s)
so the system can activate the corresponding alarm devices when an
alarm occurs.
Latch
The system can delay the alarm output for a specified time after an
alarm ends. The value ranges from 1s to 300s.
PTZ Activation
When PTZ activation is configured, the system can activate PTZ
operation when an alarm is detected.
1. Click Setup to open the PTZ Activation configuration interface.
2. Select a preset, tour, or pattern from the drop-down menu.
3. Click OK.
Tour
Click to enable a tour to be triggered by an alarm. The system supports
1/8-window tour. See Configuring Display Settings on page 217 for tour
interval setup. On the Display Settings tab, when there are two tours
enabled by default, you can configure the system so an alarm triggers
the system to enable the alarm tours you configured here. If there is no
alarm, then the system uses the tour setup that was configured in the
Display interface.
Snapshot
Click to enable the Snapshot function. Channel snapshots are taken
according to the schedule you configure. Alarm snapshots are taken
when an alarm occurs.
Voice Prompts
Select the check box to enable the playing of a voice prompt audio file
when the alarm is detected. Use the File Name drop-down list to select
the audio file to play when the alarm is detected.
Show Message
Click to enable a pop-up message on your local host PC screen to let
you know an alarm has occurred.
Send Email
The system can send an email when an alarm is detected. When you
have enabled the Snapshot function, the system can also send an
image attached to the email. Go to Network

Email to configure the
email settings.
Alarm Upload
Enable this function, and when an alarm event is detected, an alarm
message is uploaded to the NVR.
Buzzer
Click to enable the Buzzer function. When an alarm occurs, the buzzer
beeps.
Message
Select the check box to send a text message when alarm events are
detected. Go to Network

3G

Mobile to configure messaging
settings.
Log Select the check box to enable logging of alarm events.
Configuring Network Alarms

Honeywell Performance Series Specifications

General

IR Range	Up to 30m (98ft)
Weatherproof Rating	IP66
Power Supply	PoE (Power over Ethernet) IEEE 802.3af, 12 VDC
Image Sensor	1/2.8" CMOS
Vandal Resistance	IK10
Video Compression	H.265/H.264/MJPEG
Storage	MicroSD card slot (up to 256GB)
Network Connectivity	10/100 Mbps Ethernet
