HP 8712C - To Perform a Conversion Loss Calibration

I
-
Calibrating for Increased Measurement
Accuracy
Choose an Appropriate Calibration Method
To Perform a Conversion Loss Calibration
Conversion loss measurements typically utilize only a normalization
calibration. See “lb Perform a Normalization Calibration” earlier in this
chapter.
When in conversion loss measurement mode, the analyzer is using its internal
broadband detectors and pressing the (CAL) key calls up a menu for zeroing
the detectors. Zeroing the detectors helps compensate for drift due to changes
in ambient temperature. The two (CAL) selections for conversion loss mode
are:
Autozero periodically compensates for detector drift due to changes in
temperature. When autozero is selected, the detectors are automatically
zeroed approximately every five minutes. A pop-up message will briefly
appear on the analyzer’s display when the detectors are zeroed.
In manual zero mode, the analyzer zeros the detectors only when the
?f&mM Zero softkey is pressed.
I
NOTE
When zeroing the detectors, the analyzer turns off the internal RF source. If you are measuring an
external source with the broadband detectors, use M&~~val, Z&v be/ure the external source is
connected to the TRANSMISSION port.
6-15
