Step 2. Meet Electrical and Environmental
Requirements
1. Set the line voltage selector to the position that corresponds to the ac
power source you will be using.
CAUTION
Before switching on this instrument, make sure that the line voltage selector
switch is set to the voltage of the power supply and the correct fuse
(T
5A
250
V)
is installed. Assure the supply voltage is in the
specsed
range.
NOTE
The working fuse and a spare are located in the power cable receptacle. See figure 8-12.
I
I
POWER CAB:E
VOLTAGE
SELECTOR
RECEPTACLE
SWITCH
Figure l-l. Voltage Selector Switch location
PP~~C
l-4
