Measuring Reflection Response
This section uses an example measurement to describe how to calibrate
for and make a basic reflection response measurement. In this example, a
bandpass
titer
like the one that was supplied with your network analyzer is
used.
Enter
the
Measurement
Parameters
Press the following keys on the analyzer:
pEFY]
(jKiiG--
I
NOTE
This example measurement uses the default instrument parameters for a reflection response
measurement. If your particular reflection measurement requires specific parameters (such as frequency
range, source power level, number of data points, and sweep time), enter them now
