I
-
Getting Started
Performing the Operator’s Check
NETWORK ANALYZER
LOAD
Figure 2-9. Connect the load
5. Verify that the data trace falls below -30
dB.
If the data trace is off the
screen, press
[EiKF]
R~~Yxw~
L%xr&
and the
(IJ
key until the trace
moves up onto the screen.
2-18
