Measuring Transmission Response
This section uses an example measurement to describe how to calibrate for
and make a basic transmission response measurement. In this example, a
bandpass
titer
like the one that was supplied with your network analyzer is
used.
Enter
the
Measurement
Parameters
Press
c-1
on the analyzer to set the analyzer to the default mode which
includes measuring transmission on measurement channel 1.
NOTE
This example measurement uses the default instrument parameters far a transmission measurement. If
your particular transmission measurement requires specific parameters (such as frequency range, source
power level, number of data points, and
sweeptime)
enter them now
3-18
