I
-
Using Instrument Functions
Customizing the Display
Expanding
the
Displayed
Measurement
Normally, the displayed measurement is limited in size due to the
softkey
menu and the surrounding annotation. The expanded display feature
removes these size-limiting factors, with the exception of annotation inside
the normal graticule, and expands the display to the full screen size. The
remaining annotation is enlarged for better readability.
‘RI
use the expanded display feature, follow the steps below.
2.
Press @iWF).
At this point, and until you turn the expand mode off with the
EX~WK$
on OFF key, the
(ENTER)
key is used to toggle between the
expanded display and the normal display.
Because the
(ETiE@
key also functions as the
LENTRY)
key it
may
be necessary to press
4-62
The following figures illustrate the difference between a normal display and
an expanded display.
