Using Instrument Functions
Using Markers
To
Use
Polar
Format
Markers
The analyzer displays the polar marker values as magnitude and phase. You
can use these markers only when you are viewing a polar display format.
(The polar format is accessed by pressing
~~
#QXW
FWW&
PO&W
.)
To
Use
Smith
Chart
Markers
In Smith chart format, markers have a resistive value, a reactive value and
a complex impedance value. For information on interpreting Smith chart
values, see “Measuring Impedance Using the Smith Chart” in Chapter 3.
