Optimizing Measurements

Increasing Sweep Speed

Avoid

Frequency

Bandcrossings

Minimizing

the

Span

(HP

8714C

only)

Sweep time is increased when the analyzer encounters a bandcrossing point.

The frequency bandcrossing points are approximately:

1900 MHz

2310 MHz

2620 MHz

Press

(%?Ej)

and then change the start frequency, stop frequency, or span to

avoid sweeping through these band crossing points when possible.
