Using Instrument Functions
Synchronizing and Positioning the Display
The analyzer provides a CRT adjustment feature which can be used to get
an external monitor to synchronize properly, and to optimize the display’s
position. The following list explains how to use the CRT adjust features.
CAUTION
The CRT adjust settings also affect the analyzer’s built-in display.
1. Press (SYSTEM OPTIONS) SVa3tsm config CRT Adju8-t; -. When this key
is pressed a test pattern appears on the monitor(s). If you don’t want the
test pattern on the display while adjusting it, press Remove PattBr~~ .
2. If your external monitor is a sync-on-green-signal monitor, press the
Sync GXWW an OFE key to enable the sync-on-green capability.
3. Use the VW&al Position and Ho&~~&ti Positfun keys to vary
the display’s position on the monitor. After pressing one of these softkeys,
use the front panel knob, the @) ($J keys, or the numeric keypad to vary
the position of the display on the monitor.
4. For synchronizing your external monitor, use the
Vsxtical lita& Porch , HoWrantal Da& Porch ,
V~flic& Front Parch , and HoxinontaS &on% Porch keys to vary
the vertical and horizontal front and back porch times until the display is
optimal. Use Restare Defaults if necessary.
5. All of these settings are retained when the analyzer is turned off or preset,
