Automating Measurements
Displaying Measurement Results
Customized Measurement Channel Annotation
The analyzer displays measurement channel annotation above the graticule.
This annotation shows the measurement type, format, scalekliv, and
reference level.
You may replace this annotation with your own text or eliminate the
measurement channel annotation completely. ‘lb do so, use the following
command to enable user-defined annotation:
DISPlay:ANNotation:CHANnel[ll21 :USERC:STATel ~OFFIOIONIl~
For example:
DISPlay:ANNotation:CHANnell:USER ON
l To specify the string to be displayed use the command:
DISPlay:ANNotation:CHANnel[ll2] :USER:LABel[:DATA] <STRING>
For example:
DISP:ANN:CHANl:USER:LABel ‘1: SuperNotch filter, test t3’
a lb restore the default measurement channel annotation, use:
DISPlay:ANNotation:CHANnell:USER OFF
l lb turn the measurement channel annotation on or off press I-J
Mwm Displq Annotation Options Meas Annot ON off” or use
these SCPI commands:
DISP:ANN:CHAN[112] ON
DISP:ANN:CHAN[ll2] ON
7-68
