Making Measurements
Measuring Impedance Using the Smith Chart
Connect
the
DUT
NETWORK
ANALYZER
po660b
OR
NETWORK ANALYZER
DEV ICE
UNDER
TEST
0
LOAD
Figure 3-21. Equipment Setup For a Reflection Measurement of a Two-Port Device
NETWORK ANALYZER
1
RF OUT
DEVICE UNDER
TESl
PDIs5a
Figure 3-22. Equipment Setup For a Reflection Measurement of a One-Port Device
3-57
109
111
