Making Measurements
Measuring Reflection Response
h:Reflectlon
D2: off
Log Mag
5.0 dB/
Ref -15.00 dB C
-30
-35
Start 0.300 MHz
stol3 3 000.000 MHZ
Figure 3.10. Example of a Reflection Measurement Display
3. To quickly determine the titer’s return loss, press [““ARKER) and then use
the front panel knob, the m a keys, or the numeric keypad to read the
value of return loss at the desired frequency.
4. See “Using Markers” in Chapter 4 for detailed information on using
markers to interpret measurements.
