Performing the Operator’s Check
The operator’s check should be performed when you receive your instrument,
and any tune you wish to have confidence that the analyzer is working
properly. The operator’s check does not verify performance to speciiications,
but should give you a high degree of confidence that the instrument is
performing properly if it passes.
The operator’s check consists of making a transmission measurement with the
cable that was supplied with your analyzer, and a reflection measurement
with the cable and again with a 50
fl
or 75
tI
termination (load).
2-13
