Installing the Analyzer
Step 4. Configure the Analyzer
Installing
the
Analyzer
In
a
Rack
Use only the recommended rack mount kit (Option
1CM
when ordered with
the analyzer or HP part number 08712-60036 when ordered separately) with
this instrument; it needs side support rails. Do not attempt to mount it by
the front panel (handles) only. This rack mount kit allows you to mount the
analyzer with or without handles.
lb install the network analyzer in an HP
85043D
rack, follow the instructions
in the rack manual.
CAUTION
lb install the network analyzer in other racks, note that they may promote
shock hazards, overheating, dust contamination, and inferior system
performance. Consult your HP customer engineer about installation,
warranty, and support details.
CAUTION
When installing the product in a cabinet, the convection into and out of
the instrument must not be restricted. The ambient temperature (outside
the cabinet) must be less than the maximum operating temperature of the
instrument by 4
OC
for every 100 watts dissipated in the cabinet. If the
total power dissipated in the cabinet is greater than 800 watts, then forced
convection must be used.
Place other system instruments (computer, printer, plotter) where convenient,
within the HP-IB cable length limits (see
‘Ihble
l-l) or other interface cabling
limits.
1-17
