HP 8712C User Manual

I
-
I
-
Installing the Analyzer
Step 4. Configure the Analyzer
To Configure Peripheral If your system uses serial or parallel peripherals, follow the guidelines below
Settings
to configure the system. Refer to the peripheral’s manual for correct cables
and settings. The parallel and serial ports have standard Centronics DB-25
and RS232 pinouts respectively as explained in Chapter 8, “Front/Rear
Panel.’
l Serial Devices: press (m) Select Copy Port , use the entry
controls to highlight your type of printer or plotter and press Select . If
the baud rate or handshake at the top of the screen are incorrect, use the
softkeys to change them.
l Parallel Devices: press (m) Sefect CuPy Port , use the entry
controls to highlight your type of printer or plotter and press Select .
l LAN Printer (Option lF7 only): press [HARDCOPY) S@X%ct Copy Port ,
use the entry controls to highlight HP LaserJet PCL5/6 PCL5 LAN,
and press S&,o~t . If the printer IP address at the top of the screen is
incorrect, press X,AN PWrtsr IP addr to enter the correct IP address.
NOTE
When S+l+clt &yy Port is selected, the first two lines in the box that appears at the top
of the display screen show the current settings for your convenience.
NOTE
Use a PCL5 printer for fastest hardcopies. See “Configure the Hardcopy Port” in Chapter 4 for more
information.
1-16
-1
