HP 8712C - Enter the Measurement Parameters; Calibrate for a Reflection Response Measurement

Making Measurements
Measuring Impedance Using the Smith Chart
Enter the Measurement Parameters
Press the following keys on the analyzer:
[pkiEq
[MEAs]
NOTE
This example measurement uses the default instrument parameters for a reflection measurement. If
your particular measurement requires specific parameters (such as frequency range, source power level,
number of data points, and sweeptime) enter them now
Calibrate For a Reflection Response Measurement
Since impedance is a reflection measurement, you can perform a reflection
calibration to improve accuracy. Refer to “Calibrate For a Reflection Response
Measurement,” earlier in this chapter.
