Specifications and Characteristics
Measurement Port Specifications
The following specifications describe the residual system uncertainties.
These specifications apply after a user enhanced response calibration
(for transmission measurements) or one port calibration (for reflection
measurements) has been performed and with an environmental temperature
of 25 f5 OC, with less than 1 “C deviation from the calibration temperature.
Measurement Port Specifications
Directivity
Parameter
HP 8712C
HP 8714C
40 dB
40 dB
Source Match
30 dB
30 dB
load Match
300 kHz to 1300 MHz
18 dB
20 dB
> 1300 MHz to 3000 MHz
NM
18 dB
