Tasks at a glance
(Required.)
Configuring an mGRE tunnel
(Required.) Configuring routing
(Optional.) Configuring IPsec for an mGRE tunnel
Configuring an mGRE tunnel
The public address of an NHC can be statically configured or dynamically assigned. The private
address of an NHC must be statically configured.
For more information about tunnel interfaces, see tunneling configuration in Layer 3—IP Services
Configuration Guide. For more information about the interface tunnel, source, and tunnel dfbit
enable commands and other commands for a tunnel interface, see tunneling commands in Layer
3—IP Services Command Reference.
To configure an mGRE tunnel:
Step
Command
Remarks
3. Enter system view.
system-view
N/A
4. Create an mGRE tunnel
interface and enter tunnel
interface view.
interface tunnel
number
mode mgre
By default, no tunnel interfaces exist.
5. Configure a private address
for the tunnel interface.
ip address
ip-address { mask |
mask-length } [
sub
]
By default, no private address is
configured for a tunnel interface.
6. Configure a source address
or source interface for the
tunnel interface.
source
{ ip-address |
interface-type
interface-number }
By default, no source address or
source interface is configured for a
tunnel interface.
If you specify a source address, it is
used as the source IP address of
tunneled packets.
If you specify a source interface, the
primary IP address of this interface is
used as the source IP address of
tunneled packets.
7. Configure an NHRP packet
authentication key.
nhrp authentication
[
cipher
|
simple
] string
By default, no NHRP packet
authentication key is configured.
NHRP nodes do not authenticate
NHRP packets received from each
other.
8. Configure an NHRP network
ID for the mGRE tunnel.
nhrp network-id
number
By default, an mGRE tunnel does
not have an NHRP network ID.
9. Configure the holdtime for
NHRP mapping entries.
nhrp holdtime
seconds
By default, the holdtime of NHRP
mapping entries is 7200 seconds.
10. Configure an NHS
private-to-public address
mapping.
nhrp nhs
nhs-address
nbma
nbma-address
By default, no NHS private-to-public
address mappings are configured.
