HPE MSR3000 User Manual

45
Usage guidelines
If you do not specify any parameters, this command displays brief information about all mGRE
sessions on all tunnel interfaces.
Examples
# Display brief information about all mGRE sessions.
<Sysname> display mgre session
Interface : Tunnel1
Number of sessions: 2
Peer NBMA address Peer protocol address Type State State duration
10.0.0.3 192.168.180.136 C-S Succeeded 00:30:01
10.0.1.4 192.168.180.137 C-C Establishing 00:30:02
# Display brief information about mGRE sessions on the specified tunnel interface.
<Sysname> display mgre session interface tunnel 1
Interface : Tunnel1
Number of sessions: 2
Peer NBMA address Peer protocol address Type State State duration
10.0.0.3 192.168.180.136 C-S Succeeded 00:30:01
10.0.1.4 192.168.180.137 C-C Establishing 00:30:02
# Display brief information about the mGRE session with the specified peer address.
<Sysname> display mgre session interface tunnel 1 peer 10.0.0.3
Interface : Tunnel1
Number of sessions: 1
Peer NBMA address Peer protocol address Type State State duration
10.0.0.3 192.168.180.136 C-S Succeeded 00:30:01
Table 1 Command output
Field Description
Interface Name of the mGRE tunnel interface.
Number of sessions Total number of mGRE sessions on the tunnel interface.
Peer NBMA address Public address of the peer.
Peer protocol address IP address of the peer tunnel interface.
Type
mGRE session type:
• C-S—The local end is an NHC, and the peer end is
the NHS.
• C-C—The local end is an NHC, and the peer end is
an NHC.
• UNKNOWN—The local end is an NHC, and the
peer end type is unknown.
State
mGRE session state:
• Succeeded.
• Establishing.
State duration
Duration of the current session state, in the format of
hh:mm:ss.
# Display detailed information about all IPv4 mGRE sessions.
