HSD ES779 - Sensor Wiring - Versions Without Sensor S5; Sensor Wiring - Versions with Sensor S5

5 Installation and commissioning
110
HSD S.p.A. © - h0104k01a.fm120718
Sensor wiring - versions without sensor S5
Sensor wiring - versions with sensor S5
Colour Description
Green 0V sensor S1
Pink 0V sensor S2
Black 0V sensor S3*
*
Present in certain versions only.
Beige 0V sensor S4**
**
For HSK versions only; not connected in ISO versions.
Brown Sensor S1 output
Grey Sensor S2 output
Red Sensor S3* output
Orange Sensor S1+S4** output
White +24V
DC sensor S1
Yellow +24VDC sensor S2
Blue +24VDC sensor S3*
Purple***
***
For HSK versions only: weld the purple and brown wires together.
VDC sensor S4**, to be powered with the output of sensor S1
Shield Shield
Colour Description
Green ISO versions: 0V sensor S1; HSK versions: 0V sensor S1+S4
Pink 0V sensor S2
Black 0V sensor S3*
*
Present in certain versions only.
Beige 0V sensor S5
Brown ISO versions: sensor S1 output; HSK versions: sensor S1+S4 output
Grey Sensor S2 output
Red Sensor S3* output
Orange Sensor S5 output
White +24V
DC sensor S1
Yellow +24VDC sensor S2
Blue +24VDC sensor S3*
Purple +24V
DC sensor S5
Shield Shield
