HSD ES779 - Technical Datasheet Asynchronous ES789 11;13.5 Kw 380 V 350 Hz

3 Technical specifications and main parts
60
HSD S.p.A. © - h0102k01a.fm120718
3.5.11 Technical datasheet asynchronous ES789 11/13.5kW
380V 350Hz*
Motor rating plate
H1423H0246 (SP.120.150.49)
*
Discontinued.
Rated voltage V 380 380 380 380
Rated frequency Hz 233 350 733 833
Rated speed*
*
The maximum speed is specified in the “MAX RPM” box of the motor rating plate affixed to the product.
rpm 7,000 10,500 22,000 25,000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW
8 9.6 11 13.5 5 6 3.5 4.2
Rated torque Nm
10.9 13.1 10 12.3 2.2 2.6 1.3 1.6
Rated current A
27.5 33 26 32.5 13.3 16 9.5 11
Rated efficiency K 0.86
Power factor cos M 0.7
Number of poles 4
Insulation class F
Cooling Liquid
Weight kg 36
350Hz
10500 rpm
380V
25000
22000
MAX RPM
4,2
S1 continuous
11 kW-14,8 Hp
Poles: 4
S6 60%
13,5
kW - 18,1 Hp
26 A
Cos = 0,7
= 0,86
Kg
36 Kg
Liquid cooling
H1423H0246
Flussigkeitsgekuhlt
ES 789L 4P 13,50kW H1
13,5
9,6
HSD S.p.A www.hsd.it
Via della Meccanica,16
61122 PESARO (Italy)
ASYNCHRONOUS
3-PHASE MOTOR
DREHSTROM-
ASYNCHRONMOTOR
kW
Peak Power
Spitzenleistung
25,5 kW - 34,2 Hp
..
..
7 10,5
22
rpm x 1000
25
6
IP 54
8
11
5
3,5
UL-MH26206
IEC 60034-1

η
φ
HSD
Ta:20 ° C
Ins.Cl. F
