HSD ES779 - Variations with MIL Standard Electric Connectors

3 Technical specifications and main parts
36
HSD S.p.A. © - h0102k01a.fm120718
3.4.6 Variations with MIL standard electric connectors
1 Motor rating plate
8
4 through fixing bores
Ø8.5
13 Casing
2
Electric connector
(encoder)
14 Encoder compartment
9
6 fixing bores M8 thread
depth 12
15 Sensors area
3
Serial (or register)
number
16 Cylinder
10
6 fixing holes M5 for
accessories
17
Positioning bore Ø60 H8
depth 6
4
2 bores *for tool
lubricant-coolant outlet
*
M6 or G1/8”, depending on the version; check the technical data sheet.
11
Electric connectors (MIL
standard)
18
Button for manual tool
release
5 Nose
12
Hydraulic/Pneumatic
connectors
6 Shaft
7 HSK collet
1
2
3
4
5
6
10
9
15
16
18
11
12
8
13
14
8
17
7
