HSD ES779 - Variations with Configurable Power Supply Terminal Board 220;380 V

3 Technical specifications and main parts
HSD S.p.A. © - h0102k01a.fm120718
37
3.4.7 Variations with configurable power supply terminal
board 220/380V
1 Motor rating plate 4 Box of electrical connections
2
Configurable terminal board for electrical
connection of the 380V star or 220V
delta
5 Cover with gasket
6 Electric connectors (MIL standard)
7 Area of hydraulic/pneumatic connectors
3 Button for manual tool release 8 Electric connector (encoder)
1
3
4
6
5
7
8
2
