HSD ES779 - Technical Datasheet Asynchronous ES789 15;18 Kw 380 V 300 Hz with Motor Rating Plate FNZ4101851

3 Technical specifications and main parts
68
HSD S.p.A. © - h0102k01a.fm120718
3.5.15 Technical datasheet asynchronous ES789 15/18kW
380V 300Hz with motor rating plate FNZ4101851
Motor rating plate
FNZ4101851 (SP.119.150.44)
Rated voltage V 253 380 380 380
Rated frequency Hz 200 300 467 500
Rated speed*
*
The maximum speed is specified in the “MAX RPM” box of the motor rating plate affixed to the product.
rpm 6,000 9,000 14,000 15,000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW
12 14.4 15 18 12 14.4 11 13.4
Rated torque Nm
19.1 22.9 15.9 19.1 8.2 9.8 7.1 8.6
Rated current A
37.4 44 32 38 24.5 28.5 25.5 19.5
Rated efficiency K 0.84
Power factor cos M 0.87
Number of poles 4
Insulation class F
Cooling Liquid
Weight kg 36
300Hz
9000 rpm
380V
MAX RPM
S1 continuous
15 kW-20,1 Hp
Poles: 4
S6 60%
18 kW-24,1 Hp
32 A
Kg
36 Kg
IP 54
FNZ4101851
ES 789L 4P 15,00kW
14 15
6
14,4
14,4
HSD S.p.A www.hsd.it
Via della Meccanica,16
61122 PESARO (Italy)
ASYNCHRONOUS
3-PHASE MOTOR
DREHSTROM-
ASYNCHRONMOTOR
kW
9
rpm x 1000
Liquid cooling
Flussigkeitsgekuhlt
..
..
18
15000
12
12
15
11
13,4
= 0,84
Cos = 0,87
UL-MH26206
IEC 60034-1

η
φ
HSD
Ta:20 ° C
Ins.Cl. F
