HSD ES779 - Parameters of Equivalent Electrical Network Asynchronous ES789 25;30 Kw 380 V 333 Hz

3 Technical specifications and main parts
HSD S.p.A. © - h0102k01a.fm120718
87
Parameters of equivalent
electrical network asynchronous ES789 25/30kW
380V 333Hz
Electrical parameters (SP.119.150.43)
unit
Value
SINAMICS
SIMODRIVE
611 D/U
SIMODRIVE
611 A
Potenza nominale / rated power / nennleistung (S1) kW 25 P0307 P1130 P160
Corrente nominale / rated current / nennstrom (S1) A 50 P0305 P1103 P161
Tensione nominale concatenata / rated line voltage /
nennspannung
V 380 P0304 P1132 P162
Velocità nominale al carico nominale/ rated speed at
rated load /nenndrehzahl bei nennlast
rpm 9,817 P0311 P1400 P163
Frequenza nominale / rated frequency / nennfrequenz Hz 333 P0310 P1134 P164
Tensione a vuoto concatenata / no-load line voltage /
leerlaufspannung bei nennflussu
V 363 - P1135 P165
Corrente a vuoto / no-load current / leerlaufstrom A 21.3 P0320 P1136 P166
Resistenza dello statore / stator resistance /
standerwiderstand kalt (20°C)
Ohm 0.082 P0350 P1137 P167
Resistenza del rotore /rotor resistance /
lauferwiderstand kalt (20°C)
Ohm 0.108 P0354 P1138 P168
Stator leakage reactance Ohm 0.61 - P1139 P169
Stator leakage inductance mH 0.291 P0356 - -
Rotor leakage reactance Ohm 0.94 - P1140 P170
Rotor leakage inductance mH 0.45 P0358 - -
Main field reactance Ohm 9.87 - P1141 P171
Main field inductance mH 4.72 P0360 - -
Velocità di inizio indebolimento del campo / start of field
weakening speed / Einsatzdrehzahl feldschwachung
rpm 10,000 P0348 P1142 P173
Velocità massima del motore / maximum motor speed
/ Maximaldrehzahl
rpm *
*
See product motor rating plate.
P0322 P1146 P174
Gain factor Xh-Characteristic % 213 - - -
Fattore di potenza / power factor /
nennleistungsfactor
0.78 P0308 - -
Moment of inertia of the rotor kgm
2
2.7E-3 P0341 P1117 P159
Collegamento / circuit connection / schaltungsart Y/D Y - - -
