HSD ES779 - Tools for Collet HSK Assembly

B Spare parts
194
HSD S.p.A. © - h0111k01a.fm120718
Tools for collet HSK assembly
The list below shows the tools for assembling the HSK collets that can be used for the product.
H3811H1548 HSK A40 gauge for “S4 reads” adjustment
H0817H0054 0.04mm thickness spacer for adjusting HSK A40 sensors S1 and S4
H3811H0402 Kit of HSK E40 / F50 gauges for adjusting sensors S1 and S4
H3811H0110 HSK F63 gauge kit for regulating sensors S1 and S4
H3811H0775 Kit of HSK A63 gauges for adjusting sensors S1 and S4
H3811H0739 Kit of HSK E63 gauges for adjusting sensors S1 and S4
*H3407H0001 HSK A40 / E40 / F50 collet with lockscrew
H3407H0060* HSK A50 / E50 / F63 collet with lockscrew
H3407H0046* HSK A63 / E63 / F80 collet with lockscrew
*
To replace the parts it is advisable to request assistance from the manufacturer's Assistance Service.
HSK tool Manufacturer code HSK shape/size
H3811H1320 A40 / E40 / F50
H3811H1321 A50 / E50 / F63
H3811H1322 A63 / E63 / F80
Manufacturer code Description
