HSD ES779 - Graph Used to Define the Maximum Machining Speed

7 Operation and regulation
HSD S.p.A. © - h0106k01a.fm120718
133
Graph used to define the maximum machining speed
Centre of gravity curves for ES779 HSK short-nose
Centre of gravity curves for ES789 HSK
0 1 1,5 %2 2,5 %3 3,5 4 4,5 %5 5,5%%%%%%%%%%%)
0
2000
4000
6000
8000
10000
12000
14000
16000
18000
20000
22000
24000
Kg
X = 70
X = 90
X = 110
X = 130
rpm
0 1 #1,5 2 2,5 3 #3,5 4 4,5 #5 5,5 #6 6,5#########*#
0
2000
4000
6000
8000
10000
12000
14000
16000
18000
20000
22000
Kg
X = 70
X = 90
X = 110
X = 130
rpm
