PT 1000 probe performance
The thermal alarm consists of a PT1000 probe.
Its behaviour is described in the following table:
PTC 100 probe performance
The PT 100 probe used by the manufacturer is a PT 100 F1/2 DIN (A) type.
Its behaviour is described in the following table:
Temperature
(°C)
Resistance
(Ohm)
Temperature
(°C)
Resistance
(Ohm)
Temperature
(°C)
Resistance
(Ohm)
-40 843 60 1232 160 1611
-30 882 70 1271 170 1648
-20 922 80 1309 180 1685
-10 961 90 1347 190 1722
0 1000 100 1385 200 1759
10 1039 110 1423 210 1795
20 1078 120 1461 220 1832
30 1117 130 1498 230 1868
40 1155 140 1536 240 1905
50 1194 150 1573 250 1941
Temperature (°C) Resistance (Ohm) Temperature (°C) Resistance (Ohm)
-50 80.31 60 123.24
-40 84.27 70 127.08
-30 88.22 80 130.9
-20 92.16 90 134.71
-10 96.09 100 138.51
0 100 110 142.29
10 103.9 120 146.07
20 107.79 130 149.83
30 111.67 140 153.58
40 115.54 150 157.33
50 119.4 160 161.05
