HSD ES779 - General Overview and Main Parts

3 Technical specifications and main parts
HSD S.p.A. © - h0102k01a.fm120718
31
3.4 General overview and main parts
3.4.1 ES779, with free cables, with fixing grooves
1 Bore Ø30 H8 depth 4
8
Positioning bore Ø60 H8
depth 6
14 Tool holder description
2
4 bores M5 thread depth 6
for accessories
15 Serial (or register) number
9
Positioning bore Ø8 H7
depth 10
3
6 fixing holes M5 for
accessories
16 Fixing groove
4 Nose
10
2 bores* for tool
lubricant-coolant outlet
*
M6 or G1/8”, depending on the version; check the technical data sheet.
17 Motor cable positioning
5 HSK collet 18 Sensors area
6 Support surface 11 Shaft 19 Sensor cable positioning
7
6 inlet/outlet holes for
compressed air and fluids
12 Cylinder 20 Encoder compartment
13 Motor rating plate 21 Casing
17
16
20
21
18
11
8
7
10
4
1
5
14
2
3
6
9
13
15
16
12
19
