Wiring of thermal probe on front bearings
This wiring is only present in versions fitted with a PT100 thermal probe for detecting the
temperature of the front bearings.
Encoder wiring - version without “V-sense” signal
This wiring is only present in versions fitted with an encoder that doesn't supply the V-sense signal.
Encoder wiring - version with “V-sense” signal
This wiring is only present in versions fitted with an encoder that supplies the V-sense signal.
A voltage level higher than the one specified may damage the encoder reader.
Colour Description
Red Compensation
White T2
Red T1
Colour Description
Yellow A+
Green A-
Brown B+
Blue B-
Grey Z+
White Z-
Red Electricity supply*
*
For the encoder supply voltage, refer to the electrospindle technical datasheet.
Black 0V
Orange Shield
Colour Description
White A+
Brown A-
Pink B+
Black B-
Grey Z+
Yellow Z-
Red +5V
DC
Blue 0V
Green V-Sense
Purple KTY+* thermal motor alarm KTY 84-130
*
Present in certain versions only.
Beige KTY-* thermal motor alarm KTY 84-130
Screen Shield
