3 Technical specifications and main parts
HSD S.p.A. © - h0102k01a.fm120718
75
Parameters of equivalent network asynchronous ES789 15/18kW 220/380V
400Hz with motor rating plate FNZ4101850
Electrical parameters (SP.119.150.45)
unit
Value
(star / Y)
Value
(star / Y)
SINAMICS
SIMODRIVE
611 D/U
SIMODRIVE
611 A
Potenza nominale / rated power / nennleistung (S1)
kW 15 15 P0307 P1130 P160
Corrente nominale / rated current / nennstrom (S1)
A 30 52 P0305 P1103 P161
Tensione nominale concatenata / rated line voltage /
nennspannung
V 380 220 P0304 P1132 P162
Velocità nominale al carico nominale/ rated speed at
rated load /nenndrehzahl bei nennlast
rpm 11,880 11,880 P0311 P1400 P163
Frequenza nominale / rated frequency / nennfrequenz
Hz 400 400 P0310 P1134 P164
Tensione a vuoto concatenata / no-load line voltage /
leerlaufspannung bei nennflussu
V 368 213 - P1135 P165
Corrente a vuoto / no-load current / leerlaufstrom
A 8.7 15 P0320 P1136 P166
Resistenza dello statore / stator resistance /
standerwiderstand kalt (20°C)
Ohm 0.077 0.23 P0350 P1137 P167
Resistenza del rotore /rotor resistance /
lauferwiderstand kalt (20°C)
Ohm 0.114 0.34 P0354 P1138 P168
Stator leakage reactance
Ohm 0.88 2.65 - P1139 P169
Stator leakage inductance
mH 0.351 1.054 P0356 - -
Rotor leakage reactance
Ohm 1.9 5.71 - P1140 P170
Rotor leakage inductance
mH 0.76 2.27 P0358 - -
Main field reactance
Ohm 24.54 74 - P1141 P171
Main field inductance
mH 9.76 29.44 P0360 - -
Velocità di inizio indebolimento del campo / start of field
weakening speed / Einsatzdrehzahl feldschwachung
rpm 12,000 12,000 P0348 P1142 P173
Velocità massima del motore / maximum motor speed /
Maximaldrehzahl
rpm *
*
See product motor rating plate.
* P0322 P1146 P174
Gain factor Xh-Characteristic % 144 144 - - -
Fattore di potenza / power factor / nennleistungsfactor
0.8 0.8 P0308 - -
Moment of inertia of the rotor
kgm
2
2.8E-3 2.8E-3
P0341 P1117 P159
Collegamento / circuit connection / schaltungsart
Y/D Y D - - -
