HSD ES779 - Features and Performance

3 Technical specifications and main parts
40
HSD S.p.A. © - h0102k01a.fm120718
3.5 Features and performance
3.5.1 Technical datasheet asynchronous ES779 10/12kW
380kW 250Hz with motor rating plate H1423H0216
Motor rating plate
H1423H0216 (SP.120.080.45)
Rated voltage V 380 380 380 380 380 380 380 380
Rated frequency Hz 250 367 400 600 733 800 833 933
Rated speed*
*
The maximum speed is specified in the “MAX RPM” box of the motor rating plate affixed to the product.
rpm 7,500 11,000 12,000 18,000 22,000 24,000 25,000 28,000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW
10 12 10 12 9.5 11.4 7.9 9 4.6 5.5 3.6 4.3 3.1 3.7 1.6 1.9
Rated torque Nm
12.7 15.3 8.7 10.4 7.6 9.1 4.2 4.8 2 2.4 1.4 1.7 1.2 1.4 0.55 0.65
Rated current A
24 29 22.6 27.1 21.5 25.8 17.8 20.4 13.6 16.3 10 12 85 10.2 5.2 6.2
Rated efficiency K 0.83
Power factor cos M 0.8
Number of poles 4
Insulation class F
Cooling Liquid
Short-nose version kg 26
Long-nose version kg 30
250Hz
7500 rpm
380V
MAX RPM
1,9
Poles: 4
Cos = 0,8
= 0,83
26 Kg
IP 54
H1423H0216
ES 779L 4P 12,00kW H1
11,4
HSD S.p.A www.hsd.it
Via della Meccanica,16
61122 PESARO (Italy)
ASYNCHRONOUS
3-PHASE MOTOR
DREHSTROM-
ASYNCHRONMOTOR
rpm
x1000
15000
22000
12
7,5 22 24 2825
3,7
5,5
4,3
Liquid cooling
Flussigkeitsgekuhlt
..
..
kW
Peak Power
Spitzenleistung
16,1 kW- 21,6 Hp
11
12
12000
S6 60%
12 kW-16,1 Hp
24 A
S1 continuous
10 kW-13,4 Hp
30 Kg
9,5
10
4,6
1,6
28000
25000
24000
9
7,6
3,6
3,1
18
18000
8,6
10,2
15
UL-MH26206
IEC 60034-1

η
φ
HSD
Ta:20°C
Ins.Cl. F
