9 Replacing components
HSD S.p.A. © - h0108k01a.fm120718
175
Combinations of gauges and thickness spacers
To make the adjustments indicated in the next paragraph “Using the adjustment gauge kit”, the
gauges and thickness spacers must be combined as indicated in the tables below.
Kit of gauges A40 E40 F50 (measurements expressed in mm)
Adjustment Corresponding combination of gauges and thickness spacers
S1 reads (11.52) Gauge - S1 doesn't read (11.56) and 0.04 thickness spacer
S1 doesn't read (11.56) Gauge - S1 doesn't read (11.56)
S4 reads (11.32) Gauge - S4 reads (11.32)
S4 doesn't read (11.28) Gauge - S4 reads (11.32) and 0.04 thickness spacer
Kit of gauges F63 (measurements expressed in mm)
Adjustment Corresponding combination of gauges and thickness spacers
S1 reads (14.25) Gauge - S1 doesn't read (14.29) and 0.04 thickness spacer
S1 doesn't read (14.29) Gauge - S1 doesn't read (14.29)
S4 reads (14.01) Gauge - S4 (14.13) and 0.12 thickness spacer
S4 doesn't read (13.97) Gauge - S4 (14.13) and 0.04 and 0.12 thickness spacers
Kit of gauges A63 E63 (measurements expressed in mm)
Adjustment Corresponding combination of gauges and thickness spacers
S1 reads (18.25) Gauge - S1 reads (18.25)
S1 doesn't read (18.29) Gauge - S1 doesn't read (18.29)
S4 reads (18.01) Gauge - S4 reads (18.01)
S4 doesn't read (17.97) Gauge - S4 doesn't read (17.97)
