HT2800T_en_c.doc Page 133 of 275
Warning
If syringeID system is used, be careful while handling the syringe holder of the SyringeID
system (1.7.2 “Options” and 11.2 “Liquid mode”). Do not touch the connector or the
electronic circuit placed on the back of the holder. The components may be damaged. If not
used, the SyringeID holder must be stored in the antistatic bag supplied with the
packaging.
4.2.6.8 Setup configuration: SyringeID
This menu is available only for liquid mode, in case that GLP pack has been purchased (see pa
1.7.2).
Access sequence: RUN>SETTINGS>SETUP>CONFIGURATION>NEXT>SyringeID The following
parameters can be viewed/edited:
• Enable: enables or disables the SyringeID system (see paragraph 11 “Appendix A –
Glossary“).
• Reading: starts the syringeID parameter (see below) reading test. If the reading test is
successful, a screen showing the SyringeID parameters appears, otherwise an error
message is displayed (see paragraph 8.12 “SyringeID timeout“).
The SyringeID parameters are: the syringe serial number and part number, the syringe volume
and the “Plunger stroke Counter” (number of plunger strokes performed that represents a
syringe “wear and tear” indicator).
Select “Exit” to exit from this screen and return to the “Setup Configuration”” screen
(see paragraph 4.2.6 “Setup: Configuration”):
4.2.6.9 Setup configuration: BCR
This menu is available only in case that Bar Code Reader Module has been purchased (see
paragraph 1.7.2 “Options“).
Access sequence: RUN>SETTINGS>SETUP>CONFIGURATION>NEXT>BCR
