HT2800T_en_c.doc Page 23 of 275
A. 6
Letter (row) Number (column)
The letters (from A to G) indicate the rows, while the numbers indicate the columns (from 1 to 6).
In Liquid Mode HT2800T mounts a 121-position rack (2ml vials).
Figure 4: 121 position rack (liquid mode)
Each vial is identified with two digits (a letter and a number):
A. 6
Letter (row) Number (column)
The letters (from A to K) indicate the rows, while the numbers indicate the columns (from 1 to
11).
2.1.1.2 HT2800T/HT2850T Incubation Oven (Headspace and SPME
mode)/ Location for solvent vials (Liquid Mode)
On the side of the autosampler there is an incubation oven with 6 heated vial positions
(Headspace and SPME mode). The oven is equipped with a fan, which is used to to assist
temperature stabilization and the cooling down of the oven. The oven positions are labelled A-F.
