Injector injection depth and the Front Injector needle insertion speed (Very Low, Low,
Medium, High or Very high). Tap “SAVE” to save these settings, otherwise tap “ABORT”.
• Tap “DO MANUAL” to modify the alignment (if needed). A screen appears to manually
move the turret and needle. Move the turret and needle by pressing the arrows to center
the injector. Tap “STORE” to save the alignment (this button is enabled only if the touch
sensor is “ON”, so the vial locator must be touching the injector), otherwise tap “ABORT”.
Set the Front Injector injection depth and the Front Injector needle insertion speed (Low,
Medium, High or Very high). Tap “SAVE” to save these settings, otherwise tap “ABORT”.
-If the vial locator does not find the injector, the following message appears: “Injector not found”.
In this case, only the “DO MANUAL” or “ABORT” buttons are enabled.
Select “Exit” to exit from this screen and return to the “ALIGNMENT” screen (see paragraph
4.2.1 “Setup: Alignment”.
Injection depth setting in SPME mode
Injection Depth is the distance from vial locator and the Fiber tip. For different depths set,
autosampler exposes only Fiber; Fiber and needle; Fiber, needle and Fiber holder.
Warning
Ensure that:
• The needle is aligned over the centre of the vial locator on the injector;
• The vial locator fits properly on the injector;
• The needle has to enter the injector without trouble and penetrate the septum
without any excessive bending: If it does not, check the injector septum, type of
syringe used and needle tip type;
• when the needle is in the port, ensure that it has a little further room to go down
(about 1-2 millimetres).
