[Administrator-1] cluster enable
[Administrator-1] cluster
[Administrator-1-cluster] mngvlanid 10
[Administrator-1-cluster] quit
# Configure member switch 1.
[Member-1] cluster enable
[Member-1] cluster
[Member-1-cluster] mngvlanid 10
[Member-1-cluster] quit
# Configure member switch 2.
[Member-2] cluster enable
[Member-2] cluster
[Member-2-cluster] mngvlanid 10
[Member-2-cluster] quit
# Configure member switch 3.
[Member-3] cluster enable
[Member-3] cluster
[Member-3-cluster] mngvlanid 10
[Member-3-cluster] quit
After the topology collection function is enabled manually on the administrator switch, check
the device information collected through NTDP and you can find the MAC address and types
of related devices.
<Administrator-1> ntdp explore
<Administrator-1> system-view
[Administrator-1] display ntdp device-list
The device-list of NTDP:
------------------------------------------------------------------------------
MAC HOP IP PLATFORM
------------------------------------------------------------------------------
0004-0004-0004 2 S5700
0003-0003-0003 1 S5700
0002-0002-0002 1 S5700
0001-0001-0001 0 S5700
Step 5 Create a cluster.
NOTE
Following steps can be performed only on the administrator switch.
# On the administrator switch, set the range of IP addresses that can be assigned to the cluster
to 10.0.0.0/8, in which the IP address assigned to the administrator switch is 10.0.0.1/8.
[Administrator-1] cluster
[Administrator-1-cluster] ip-pool 10.0.0.1 8
# Create a cluster named HUAWEI on the administrator switch.
[Administrator-1-cluster] build HUAWEI
[HUAWEI_0.Administrator-1-cluster]
After the previous configuration, check information about the cluster to which the device
belongs. You can find that the device name is changed, the cluster name is HUAWEI, and the
management VLAN ID is 10.
[HUAWEI_0.Administrator-1-cluster] display cluster
Cluster name:"HUAWEI"
Role:Administrator switch
management vlan id : 10
Cluster multicast MAC address : 0180-c200-000a(default)
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 3 HGMP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
143

Huawei Quidway S5700 Series Specifications

General

Category	Switch
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 95% (non-condensing)
Series	Quidway S5700
Forwarding Performance	Up to 96 Mpps
Ports	24 or 48 x 10/100/1000Base-T ports
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C
Fixed GE Ports	24 or 48
Uplink Ports	4 x GE SFP ports
Routing Protocols	RIP, OSPF, BGP
Management	SNMP, RMON, CLI, Web
VLAN	4094 VLANs
PoE	Optional
