Cluster auto-join : disabled
Handshake timer:10 sec
Handshake hold-time:60 sec
IP pool:10.0.0.1/8
No logging host configured
No SNMP host configured
No FTP server configured
No SFTP server configured
cluster-member ftp-timeout: 300 sec(default)
Cluster SNMP NAT capability : enabled
Cluster FTP NAT capability : disabled
There are 1 member(s) in the cluster, and 0 of them are down.
On the administrator switch, check information about candidate switches, you can find all the
candidate switches and their types.
[HUAWEI_0.Administrator-1-cluster] display cluster candidates
MAC HOP IP PLATFORM
0004-0004-0004 2 S5700
0003-0003-0003 1 S5700
0002-0002-0002 1 S5700
Step 6 Add member switches.
NOTE
l Following steps can be performed only on the administrator switch.
l Take the mode of automatically adding member switches as an example. To add member switches
manually, see Adding a Member Switch.
# Add all candidate switches to the cluster.
[HUAWEI_0.Administrator-1-cluster] auto-build
Collecting candidate list, please wait...
Candidate list:
Name Hop MAC Address DeviceType
Member-1 1 0002-0002-0002 S5700
Member-2 1 0003-0003-0003 S5700
Member-3 2 0004-0004-0004 S5700
Warning: Add all to cluster?(Y/N) y
Info: Cluster auto-build is complete.
Added 3 member(s) into the cluster successfully.
After the previous configuration, check information about the administrator switch and member
switches in the cluster on the administrator switch. You can find that all the member switches
are added to the cluster and in the Up state.
[HUAWEI_0.Administrator-1-cluster] display cluster members
The list of cluster member:
------------------------------------------------------------------------------
SN Device Type MAC Address Status Device Name
------------------------------------------------------------------------------
0 S5700 0001-0001-0001 Admin HUAWEI_0.Administrator-1
1 S5700 0002-0002-0002 Up HUAWEI_1.Member-1
2 S5700 0003-0003-0003 Up HUAWEI_2.Member-2
3 S5700 0004-0004-0004 Up HUAWEI_3.Member-3
Step 7 Assign an IP address to VLANIF 10.
# To ensure the normal communication between member switches in the cluster and devices out
of the cluster, assign an IP address to VLANIF 10 on the administrator switch.
# Assign an IP address to VLANIF 10.
[HUAWEI_0.Administrator-1] interface vlanif 10
[HUAWEI_0.Administrator-1-Vlanif10] ip address 1.0.0.1 8
[HUAWEI_0.Administrator-1-Vlanif10] quit
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 3 HGMP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
144
