2–39
Chapter 2. Setting Up the Printer
2. Open the printer cover. See Figure 2–30.
3. On pedestal models, swing the operator panel out of the way. The
operator panel can be pulled toward you to provide clearance.
See Figure 2–30.
Forms
Thickness
Lever
Tractor Door
Figure 2–31. Forms Thickness Lever
4. Raise the forms thickness lever as far as it will go. See Figure 2–31.
5. Open the tractor doors. See Figure 2–31.
6. Remove the ribbon spools from the package.
To Next Page
