2–44
6400 Line Matrix Printers Setup Guide, Cabinet and Pedestal Models
EDGE
OF
PAPER
BOX
Figure 2–37. Paper Supply Label Location (Cabinet Models Only)
4. Prepare the paper supply:
• Cabinet models: Open the front door of the printer cabinet. Place the
paper supply inside the printer, on the floor of the cabinet. Align the
paper supply with the front label on the floor of the printer. Ensure
that the paper pulls freely from the box. See Figure 2–37.
• Pedestal models: Place the paper supply on the floor in front of the
printer, or on the optional paper shelf, if attached. Ensure that the
paper pulls freely from the box.
Paper Slot is 8 inches
below printer base
Paper Slot
Figure 2–38. Feeding the Paper
To Next Page
