Press the UP and DOWN arrow keys to change the current digit. Press the Enter key to advance to the
next digit. The default password is 0000. When you are logged in, you can change the password with the
Change Login Password command. See “Configuring Operator Panel settings” on page 72.
Screen elements
The Operator Panel displays a single menu item (▌1▐ in Figure 11) on each screen. The existence of other
menu items above and below the currently displayed item is indicated by the arrows (▌2▐ in Figure 11)
on the right side of the screen.
In the Configuration menu, the current configuration setting is indicated by an asterisk (▌3▐ in Figure 11)
on the right side of the screen. For example, in Figure 11, the I/O station is enabled. When a
configuration setting is changed, the confirmation screen in Figure 12 displays. Press Enter to confirm, or
Cancel to return to the previous screen.
Web User Interface
You can use the Web User Interface to update the library and drive firmware, and to download error
logs, drive memory dumps, and other library data.
Before the TS2900 Tape Autoloader can be managed over a network with the Web User Interface, set up
the initial network configuration of the library with the Operator Panel. For information, see
“Configuring network settings” on page 54.
Logging in
To log in to the Web User Interface from Internet Explorer, you must enter the IP address of the library.
The IP address can be obtained with the View Settings command from the Operator Panel. For example,
http://192.168.1.1.
After the Web User Interface is started, the login window is displayed.
Figure 11. Screen elements
Figure 12. Confirmation screen
16 IBM TS2900 Tape Autoloader: Setup, Operator, and Service Guide Machine Type 3572
