IDEC SmartRelay Manual
9
Getting started with IDEC SmartRelay
Versions
The following IDEC SmartRelay versions are available:
Expansion modules
The following expansion modules can be connected to IDEC SmartRelay:
Symbol Designation Supply voltage Inputs Outputs Properties
FL1F-H12RCE 12/24VDC
8 digital
1)
4 relays
(10 A)
FL1F-H12RCC 100VAC/VDC to
240VAC/VDC
8 digital 4 relays
(10A)
FL1F-H12SCD 24 VDC
8 digital
1)
4 solid state
24V/0.3 A
FL1F-H12RCA
3)
24 VAC/VDC 8 digital 4 relays
(10A)
FL1F-B12RCE 12/24 VDC
8 digital
1)
4 relays
(10A)
no display unit
no keyboard
FL1F-B12RCA
3)
24 VAC/VDC 8 digital 4 relays
(10A)
no display unit
no keyboard
FL1F-B12RCC
2)
100VAC/VDC to
240VAC/VDC
8 digital 4 relays
(10A)
no display unit
no keyboard
1)
Of those can be used alternatively: 4 analog inputs (0V to 10V) and 4 fast digital inputs.
2)
100-240 VAC/VDC versions: AC input group has two groups consisting of 4 inputs each. Each input
within a group must be connected to the same phase. It is possible to interconnect groups with a
different phase.
3)
The digital inputs can be operated with P or N action.
Symbol Name Power supply Inputs Outputs
FL1F-M08B2R2 12/24 VDC 4 digital 4 relays (5A)
FL1F-M08B1S2 24 VDC 4 digital 4 solid state 24V/0.3A
FL1F-M08D2R2
3)
24 VAC/VDC 4 digital 4 relays (5A)
FL1F-M08C2R2 100VAC/VDC to
240VAC/VDC
4 digital
1)
4 relays (5A)
FL1F-J2B2 12/24 VDC 2 analog
0V to 10V or
0/4mA to 20mA
2)
None
FL1F-K2BM2 24 VDC None 2 analog
0VDC to 10VDC or
0/4mA to 20mA
4)
1) Different phases are not allowed within the inputs.
2) 0V to 10V, 0/4mA to 20 mA can be connected optionally.
3) Digital inputs can be operated either with P or with N action.
4) 0V to 10 V, 0/4mA to 20 mA can be connected optionally.
