Getting started with IDEC SmartRelay
IDEC SmartRelay Manual
8
Analog input module
FL1F-J ①②③
① Number of Inputs
② Resolution B: 10bit
③ Terminal type 2: non-removable terminal
Analog output module
FL1F-K ①②③④
① Number of Outputs
② Resolution B: 10bit
③ M: 0 ... 10V, 0/4 ... 20 mA
④ Terminal type 2: non-removable terminal
Text Display
FL1F- ①②
① RD: Remote Display
② Version type
Symbols
Version with display unit is equipped with 8 inputs, 4 outputs and 1 Ethernet interface.
Version without display unit is equipped with 8 inputs, 4 outputs and 1 Ethernet interface.
The digital module is equipped with 4 digital inputs and 4 digital outputs.
The analog module is equipped with 2 analog inputs or 2 analog outputs, according to the
device type.
The Text Display module is equipped with 2 Ethernet interfaces.
