Web server
5.4 Operating the virtual module on the Web server
IDEC SmartRelay Manual
242
• On the Text Display:
You can click or tap or to tick manually for available messages.
Viewing message text ticking
If you have configured message ticking settings on WindLGC according to the instructions in
the Online Help for WindLGC, you can see the message text ticking by lines or characters on
the virtual Base Module or Text Display.
Checking backlight color status
If you have configured backlight color settings on WindLGC according to the instructions in
the Online Help for WindLGC, you can see the same backlight effect displayed on the virtual
Base Module or Text Display.
Setting the configurable parameters
If you have configured to show certain parameters on Base Module or Text Display according
to the instructions in the Online Help for WindLGC, you can see them displayed on the
screen.
Double-click or double-tap on the displayed parameter to activate the parameter modification
dialog. A parameter is grayed out when it is not editable.
Note
The and are gray, indicating they are not applicable in viewing message texts.
