IDT 8A3 Series - STICKY_STATUS_CLEAR.IN8_TO_15_MON_STICKY_STATUS_CLEAR

103©2018 Integrated Device Technology, Inc September 12, 2018
8A3xxxx Family Programming Guide
STICKY_STATUS_CLEAR.IN8_TO_15_MON_STICKY_STATUS_CLEAR
Clear sticky reference monitor bits for a particular input.
IN2_MON_STICKY_CLEA
R[2]
RW1C 0 Write 1 to clear the sticky bits of input 2.
IN1_MON_STICKY_CLEA
R[1]
RW1C 0 Write 1 to clear the sticky bits of input 1.
IN0_MON_STICKY_CLEA
R[0]
RW1C 0 Write 1 to clear the sticky bits of input 0.
Table 124: STICKY_STATUS_CLEAR.IN8_TO_15_MON_STICKY_STATUS_CLEAR Bit Field Locations and
Descriptions
Offset
Address
(Hex)
STICKY_STATUS_CLEAR.IN8_TO_15_MON_STICKY_STATUS_CLEAR Bit Field Locations
D7 D6 D5 D4 D3 D2 D1 D0
001h IN15_MON_
STICKY_CL
EAR[7]
IN14_MON_
STICKY_CL
EAR[6]
IN13_MON_
STICKY_CL
EAR[5]
IN12_MON_
STICKY_CL
EAR[4]
IN11_MON_
STICKY_CL
EAR[3]
IN10_MON_
STICKY_CL
EAR[2]
IN9_MON_S
TICKY_CLE
AR[1]
IN8_MON_S
TICKY_CLE
AR[0]
STICKY_STATUS_CLEAR.IN8_TO_15_MON_STICKY_STATUS_CLEAR Bit Field Descriptions
Bit Field Name Field Type Default Value Description
IN15_MON_STICKY_CLE
AR[7]
RW1C 0 Write 1 to clear the sticky bits of input 15.
IN14_MON_STICKY_CLE
AR[6]
RW1C 0 Write 1 to clear the sticky bits of input 14.
IN13_MON_STICKY_CLE
AR[5]
RW1C 0 Write 1 to clear the sticky bits of input 13.
IN12_MON_STICKY_CLE
AR[4]
RW1C 0 Write 1 to clear the sticky bits of input 12.
IN11_MON_STICKY_CLE
AR[3]
RW1C 0 Write 1 to clear the sticky bits of input 11.
IN10_MON_STICKY_CLE
AR[2]
RW1C 0 Write 1 to clear the sticky bits of input 10.
IN9_MON_STICKY_CLEA
R[1]
RW1C 0 Write 1 to clear the sticky bits of input 9.
IN8_MON_STICKY_CLEA
R[0]
RW1C 0 Write 1 to clear the sticky bits of input 8.
STICKY_STATUS_CLEAR.IN0_TO_7_MON_STICKY_STATUS_CLEAR Bit Field Descriptions
Bit Field Name Field Type Default Value Description
